Appendix A, Type Menu Reference (continued)
20 Call Program
Call Program
------------------------------
Program Number: 1
[F1] OK
Key Press Function
>
Executes an existing program number within the current program. If no program exists for the program
number being called, an error occurs.
21 Set I/O
Set I/O
------------------------------
1 Input
2 Output
Select: _
[F1] OK
Set I/O (Input)
------------------------------
Port 1-8: 1
Off(0)/On(1): 1
Goto Label: 1
[F1] OK
Set I/O (Output)
------------------------------
Port 1-8: 1
Off(0)/On(1): 0
[F1] OK
Key Press Function
>
Sets the value of an output signal or checks the status of an input signal. Refer to “I/O Port” on
page87 for input / output port technical data.
Setting Description
1 Input Enter the input port number (1–8), the input status (1=ONor0=OFF), and the
address (Goto Label) for the program to go to when that input status occurs.
2 Output Enter the output port number (1–8) and whether the output should be turned ON or
OFF (1=ONor0=OFF).
