E Series Automated Dispensing System
106 www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
22 Fill Area
Fill Area 1/2
------------------------------
Fill Type: 2
1 Rectangle 5 Circle Out
2 Rectangle In 6 Polygon In
3 Rectangle Out 7 Polygon Out
4 Circle In
[F1] OK [F2] Next
Fill Area 2/2
------------------------------
Width: 1.29 mm
Band: 13.17 mm
[F1] OK [F2] Next
Key Press Function
>
Fills a dened area in a specic way using the specied Width and Band parameters. Refer to “Example
Illustrations of Fill Area Parameters” on page107.
Parameter Description (refer to “Example Illustrations of Fill Area Parameters” on page107)
Fill Type 1 Rectangle
2 Rectangle In
3 Rectangle Out
4 Circle In
5 Circle Out
6 Polygon In
7 Polygon Out
Width The distance (in mm) between the ll dispense lines.
Range: 0–500 (mm)
Band The width (in mm) of the ll area.
Range: 0–500 (mm)
NOTE: Band distance is ignored for rectangle Fill Type 1 because this function is not
supported.
Appendix A, Type Menu Reference (continued)
