E Series Automated Dispensing System
107www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
Fill Area Type 2. Rectangle In
This command lls the dened area by moving the tip along a square, spiral-shaped path from the outside of the rectangle to the
center. After entering a Fill Area Rectangle In command, enter a Line Start point at the top left corner of the area to be lled and a
Line End point at the bottom right corner of that area.
NOTE: Use Polygon In or Polygon Out for a rotated square shape.
Line Start
Line End
Fill Area
EXAMPLES:
Width = 5 mm
Band = 15 mm
Width = 5 mm
Rectangle In when Width = 5 and Band = 0 Rectangle In when Width = 5 and Band = 15
Appendix A, Type Menu Reference (continued)
Example Illustrations of Fill Area Parameters
Fill Area Type 1. Rectangle
This command lls the dened area by passing the tip back and forth (in an S-shaped path) at the specied Width. After entering
a Fill Area Rectangle command, enter a Line Start point at the top left corner of the area to be lled and a Line End point at the
bottom right corner of that area.
NOTES:
• Use Polygon In or Polygon Out for a rotated square shape.
• Band distance is ignored for the Rectangle ll type because this function is not supported.
Line Start
Line End
Fill Area
EXAMPLE:
Width = 5 mm
Rectangle when Width = 5
