27 Park Position
Key Press Function
>
Moves the dispensing tip to the registered location, pauses the system, and keeps the system paused
until the START button is pressed.
28 Height Sensor
[Height Sensor]
01 Setup
02 Sensor Position
03 Initial Height Detect
04 Offset Program
Key Press Function
>
Measures the height of an object on a workpiece where a dispense dot is to be placed; the measured
data is then used to adjust dispensing accordingly for any height changes between workpieces.
NOTE: For this functionality, the optional height sensor must be installed and set up. Refer
to”Appendix D, Height Sensor Setup and Use” on page128 for all information related to the height
sensor.
Appendix A, Type Menu Reference (continued)
To Next Page
