24 Dummy Point
Dummy Point 1/2
------------------------------
X: 130.93 mm
Y: 37.39 mm
Z: 45.54 mm
[F1] OK [F2] Next [F3] Current
Dummy Point 2/2
------------------------------
Speed: 10.0 mm/s
[F1] OK [F2] Next
Key Press Function
>
Registers the current XYZ location as a Dummy Point. The dispensing tip passes through this point. A
Dummy Point is useful for avoiding obstacles on the workpiece.
• Press F1 to set the Dummy Point at the displayed coordinates
• Press F3 to set the Dummy Point at the current dispensing tip location, updating the XYZ
coordinates accordingly.
SPEED sets the speed at which the robot travels as it moves through the Dummy Point.
Range: 0–500 (mm/s)
25 Wait Time
Wait Time
------------------------------
Value: 1.0 s
[F1] OK
Key Press Function
>
Adds a time delay at the current XYZ location. When this command occurs, the system stops
dispensing and waits for the specied Wait Time Value.
Range: 0–99999 (s)
26 Stop Point
Stop Point
------------------------------
X: 130.93 mm
Y: 37.39 mm
Z: 45.54 mm
[F1] OK [F3] Current
Key Press Function
>
Registers a Stop Point at the current XYZ location. When this command occurs, the dispensing tip
moves to the registered location, pauses the system, and keeps the system paused until the START
button is pressed.
• Press F1 to set the Stop Point at the displayed coordinates.
• Press F3 to set the Stop Point at the current dispensing tip location, updating the XYZ coordinates
accordingly.
