E Series Automated Dispensing System
91www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
04 Arc Point
Arc Point
------------------------------
X: 130.93 mm
Y: 37.39 mm
Z: 45.54 mm
[F1] OK [F3] Current
Key Press Function
>
Registers the current XYZ location as an Arc Point. Arc points dispense material along an arc or circular
path.
Appendix A, Type Menu Reference (continued)
05 Line End
Line End 1/4
------------------------------
X: 130.93 mm
Y: 37.39 mm
Z: 45.54 mm
[F1] OK [F2] Next [F3] Current
Line End 2/4
------------------------------
Shutoff Distance: 0.00 mm
Shutoff Delay: 0.00 s
Dwell Time: 0.00 s
[F1] OK [F2] Next
Line End 3/4
------------------------------
Backtrack Length: 0.00 mm
Backtrack Gap: 0.00 mm
Backtrack Speed: 10.0 mm/s
Type 0| 1\ 2] 3/ 4[: 0
[F1] OK [F2] Next
Key Press Function
>
Registers the current XYZ location as a Line End point
Parameter Description
Shutoff Distance The distance before the end of a line when the dispenser closes to prevent excess uid
from being deposited at the end of the line, as shown in the illustration below.
Range: 0–100 (s)
Shutoff Delay The time the dispenser stays open after it stops at the end of a line.
Range: 0–100 (s)
Dwell Time The delay time that occurs at the end of a line after the dispenser turns off. This allows
the pressure to equalize before the tip moves to the next point.
Range: 0–1000 (s)
Backtrack Length The distance the dispensing tip travels away from the Line End point.
Range: 0–100 (mm)
Backtrack Gap The distance the dispensing tip raises as it moves away from the Line End point. This
value must be less than the ZClearance value for that point.
Range: 0–100 (mm)
Backtrack Speed The speed of the dispensing tip backtrack movement.
Range: 0.1–200 (mm/s)
Continued on next page
