28 Océ TCS400 User manual
The on-line mode
When the printer is in the on-line mode, the green LED is on. The screen of the
printer operator panel displays the following five information cards.
[1] On-line mode - Information cards
[1] On-line mode - Information cards
Information card Displayed information
Job information
■ Job status
■ Job name
■ Progress indication
■ Selected print mode.
Media information The media types loaded on the system .
Ink level information The ink level of each ink tank. There are four
indication types.
■ Percentage of ink in a tank (1% - 100%).
■ 'Ink tank empty' (0%). The indication for the
empty tank blinks.
■ The ink tank is not in place. The indication
shows a dashed rectangle.
■ Possible obstruction of ink path. (see
‘Miscellaneous errors’ on page 208)
Printhead information The status of each printhead. There are three
status types.
■ All printheads OK
■ Defective printheads
During the last check in the 'Optimize print
quality' wizard, failed nozzles were detected.
The printer can continue to print. Use the
'Optimize print quality' to check for failed
nozzles and to recover the failed nozzles. The
last time the printheads were checked is
displayed on the lower left corner off the
screen. (see ‘Use the Optimize print quality
wizard’ on page 141).
System information
■ Error messages and warnings about the
maintenance cassette.
■ Make a demo print
■ Change the language.
