System specifications 291
Output sizes Width
■ DIN: From 17x23" to 33x47", 36", and 28x39"
■ ANSI: From 22" to 36"
Length
■ 9.6 - 200 inches
Drawing margins
■ Leading and trailing strip: 5 mm
■ Left and right side: 3 mm
Width detection Automatic
Media types
■ Uncoated: 20 - 30 lb. bond
■ Coated: 24 - 30 lb. bond
■ Specialties
Calibration
■ Automatic printhead alignment
■ Failing nozzle compensation
■ Unattended printing in the overnight mode.
Dimensions 58.44" x 29.72" x 78.4" (H x D x W)
Voltage 100-120 / 230 V
Frequency 50/60 Hz
Power consumption
■ EPA-sleepmode (printer and Océ Power Logic
®
controller, not including the monitor)
< 39 W
■ Standby
110 W
■ In operation
160 W
Weight 363 - 396 lbs.
Safety approvals TüV GS, CETECOM, CE, UL, (c)UL, CB, FCC
Class B
Other
■ Maintenance cassette.
■ EPA Energy Star
®
compliant.
