© 2011 Omnicell, Inc. 1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G
Installing a G4 Console 12-13
Prepare for Installation of the G4 Console
2. Remove the E-Box lid.
3. Check the velcro straps that secure the battery and ensure they are secure. Tighten the straps if
they are loose.
Figure 12-19. Tighten the velcro straps around the battery
4. Connect the battery cable to the PowerCom4 board.
Figure 12-20. Connect the battery to the PowerCom4 board
