OmniCell 2-Cell CTPC - A-2 Appendix A: Part List

A-2 Appendix A: Part List
1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G © 2011 Omnicell, Inc.
14-7020
14-7021
15-7090
15-7091
unlit drawer MODEL,OMD48,4/96-UNLIT,MATRIX,DRAWER
MODEL,OMD4,4-BIN,MATRIX DRAWER,(UNLIT)
DRAWER,MATRIX,4/96 BIN UNLIT,OMD48,NO LINER
DRAWER,MATRIX,4-BIN UNLIT,OMD4,NO LINER
Unlit Matrix Drawers
14-8017 rail frame MFG,ASSY,RAIL,OMNIDISPENSER RX1
Rail Frame
15-1100 cable plate MFG,ASSY,CABLE,W/MOUNTING PLATES,SUTURE
From a Suture Rack
15-1119 keyboard MFG,ASSY,USB,KEYBOARD,QWERTY,ENGLISH,CTPC
Keyboard
15-2117 manual override MFG ASSY,MANUAL OVERRIDE,KEY MOUNT,RX
Manual Override
15-2122 manual override cover MFG ASSY, MANUAL OVERRIDE COVER, CAM LOCKS #2202 & #2232
Manual Override
Cover
Removal Procedure
15-2128-20 5-pin cable
12-pin printer cable
keyboard door
MFG ASSY, KEYBOARD BEZEL, USB K/B, W/ APS PTR, CTPC, ETX2
Keyboard Door Bezel
15-2130-30 LCD bezel
touchpad
MFG,ASSY,LCD BEZEL,USB K/B,10.4” NEC SVGA/LVDS
TOUCH PAD, SYNAPTICS, TM-00301-005 (#71-1165)
LCD Bezel Assembly
Touch Pad
15-7020 false door front MFG,ASSY,DRAWER,FRONT,DUMMY RX2
Double-Deep Drawer
15-7035 manual override lever MFG,ASSY,PULL,LEVER,MANUAL OVERRIDE,RX
9-drawer Carrier
15-7073 manual override cover MFG,ASSY,COVER,MANUAL OVERRIDE,PROFILE,RX2
9-drawer Carrier
OmniDispenser
15-7075
15-7076
dividers KIT,DIVIDER,24-BIN,LIT,MATRIX
KIT,DIVIDER,4/96,BIN,UNLIT,MTR
Bin Configuration
15-8016 top bayonet MFG,ASSY,TOP,BAYONET OMNIDISPENSER,OMNISUPPLIER
Ribbon Cable
15-8017 second bayonet MFG,ASSY,MIDDLE,BAYONET OMNIDISPENSER,OMNISUPPLIER
Ribbon Cable
15-8018
15-8022
bottom bayonet MFG,ASSY,BOTTOM,BAYONET,OMNIRXOMNIDISPENSER
MFG,ASSY,BOTTOM,BAYONET OMNISUPPLIER,OMNIDISPENSER
Bottom Bayonet
40-1015 CT PC PowerCom2 box PCBA,POWERCOM2,CTPC,BOX (inactive)
Color Touch PC Box
40-1050 CT PC PowerCom3 box PCBA PCBA,POWERCOM3 PLUS,UNIVERSAL
Color Touch PC Box
40-2003
40-2004
40-7031
SPC board PCB,ASSY,SPC,MAIN,OMNI,2 (NO,SWITCH)
PCB,ASSY,SPC,PC,OMNI,2 (NO,SWITCH)
PCB,ASSY,CARRIER,RX2
SPC Board
SPC Board and Cable
Drawer Connect
Board
40-3001
40-7051
drawer connect board PCB,ASSY,DRAWER,CONTROLLER
PCB,ASSY,CARRIER,3-DRAWER
Drawer Connect
Board
Part # Part Name Agile Description Where Used
Table A-1. 1-, 2-, 3-cell cabinet service part list
