© 2011 Omnicell, Inc. 1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G
A-1
Appendix A: Part List
Link back to the procedure that calls out the given part using the cross reference in the Where Used
column.
Note:
In some cases, parts are listed as if needed and may not be referenced in the procedure text.
Part # Part Name Agile Description Where Used
11-4111
11-4112
11-4113
11-4114
11-4115
door MFG,ASSY,DOOR,FULL-HIGH,OMNI,2
MFG,ASSY,DOOR,2/3,OMNI,2
MFG,ASSY,DOOR,1/3,MIDDLE OMNI,2
MFG,ASSY,DOOR,1/3,LOWER OMNI,2
MFG,ASSY,DOOR,PC,OMNI,2
Doors
12-3104 cath rack OPTION,KIT,MODEL,OCR48 OMNICATHLAB,RACK
From a Catheter Rack
12-3105 suture rack OPTION,KIT,MODEL,OSR24,SUTURE,RACK
From a Suture Rack
12-3109 pull- out shelf OPTION KIT,MODEL PS1,PULL-OUT SHELF
Pull-out Shelf
13-3109 shelf ASSY,PULL-OUT SHELF
Three-Drawer
Pharmacy Module
13-7000 supply drawer MFG,ASSY,DRAWER,CARRIER,RX1
Supply Drawer
13-7002 9-drawer carrier MFG,ASSY,DRAWER,CARRIER,RX2
9-drawer Carrier
13-7003 3-drawer carrier MFG,ASSY,DRAWER,CARRIER,3-DWR
3-drawer Carrier
14-1100 numeric keypad MFG,ASSY,KEYPADS
Numeric Keypad
14-1284 PC box cover MFG,ASSY,COVER,CT,PC,BOX
LCD Bezel Assembly
14-2107 wireway MFG ASSY,WIREWAY,MAIN,OMNI2,SUPPLY
Wireway
14-7008
14-7009
double deep drawer MODEL,OLL6,LARGE,LOCKING DRAWER,RX2
MODEL,OSL6,LARGE,SENSING DRAWER,RX2
Double-Deep Drawer
14-7013
14-7015
14-7019
14-7023
14-7024
pharmacy drawer MODEL,OSL12,REGULAR,SENSING DRAWER,RX2
MODEL,OSL24,24-BIN,SENSING DRAWER,RX2
MFG,ASSY,96-SD,DRAWER,RX2
MFG,ASSY,2222,SD,DRAWER,RX2
MFG,ASSY,3131,SD,DRAWER,RX2
Pharmacy Drawer
Removal Procedure
14-7016
15-7089
lit drawer MODEL,OLMD24,24-LIT,MATRIX,DRAWER
DRAWER,MATRIX,24 BIN LIT,OLMD24,NO LINER
Lit Matrix Drawers
Table A-1. 1-, 2-, 3-cell cabinet service part list
