© 2011 Omnicell, Inc. 1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G
Frames and Wireways 2-15
Wireway Removal
2. Remove the bottom bayonet.
Figure 2-26. Remove the bottom bayonet from the frame
3. Disconnect the ribbon cables from the wireway.
Figure 2-27. Disconnect the ribbon cables from the wireway
3-drawer Carrier
The removal procedure for the 3-drawer carrier is similar to the 9-drawer carrier.
