© 2011 Omnicell, Inc. 1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G
8-1
Drawer Connect Board
Introduction
The drawer connect board interfaces the SPC board with the pharmacy controller module. It
distributes power and communication data through its connectors from the SPC to the pharmacy
drawers. The drawer connect board also protects the pharmacy drawers from electrical shorts and
overloads.
This chapter provides the removal procedure. Installation can be done by performing the removal
procedure in reverse order.
Tools List
The following tools are required to install the CT PC Box:
Torx T15 screwdriver
1/16” Allen wrench
Removal Procedure
1. Perform a graceful shutdown of the CT PC Box.
2. Remove the manual override cover on the pharmacy drawers.
Figure 8-1. Remove the Manual Override Cover
3. Remove all of the drawers in the pharmacy carrier.
