© 2011 Omnicell, Inc. 1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G
Frames and Wireways 2-13
Wireway Removal
Restock Door
1. Remove the two Phillips head screws securing the trunnion bars to the module frame.
Figure 2-22. Remove the screws securing the trunnion bars to the module frame
2. Remove the three screws securing the fix inhibitor bracket.
Figure 2-23. Remove the three screws securing the fix inhibitor bracket
