Appendix A: Part List A-5
71-3000
71-3002
71-3003
71-3007
71-3008
switchpanel SWITCHPANEL,SHELF,GREEN
SWITCHPANEL,12-POSITION,CATH
SWITCHPANEL,8,POSITION,SUTURE
SWITCHPANEL,SHELF,BLUE
SWITCHPANEL,DRAWER,BLUE
Shelves
From a Shelf
From a Supply Drawer
From a Pull-out Shelf
From a Suture Rack
From a Catheter Rack
Switchpanel and Cable
73-1002 speaker SPEAKER, 10MM X 70MM, 8 OHM, 2W
Speaker
80-9038 LED panel
cable plate
LED, 5MM, GREEN, PANEL MOUNT, ROH
From a Catheter Rack
LED plate
91-3005 (rail) slide 91-3005SLIDE,CATH,ACCURIDE,C3640-20
Rail Slide
91-7033 door bumper BUMPER 1.75,O.D.,X,2.9375
Three-Drawer
Pharmacy Module
91-8012
91-8013
trunnion bars (screws) ASSEMBLY,TRUNNION,BAR,LEFT OMNIDISPENSER
ASSEMBLY,TRUNNION,BAR,RIGHT OMNIDISPENSER
Restock Door
92-1000
92-1002
92-1013
92-1015
#2036 key
lock
CAM,LOCK,#2036
CAM,LOCK,#2202
CAM,LOCK,#7202
CAM,LOCK,#7232
LCD Bezel Assembly
CT PC Box Removal
Locks and Latches
92-1001
92-1011
(manual override cover) lock KEY,RING,.48,O.D
CAM,LOCK,#2232
9-drawer Carrier
OmniDispenser
94-6005 (drawer) nuts NUT,HEX,4-40,SS
From a Supply Drawer
94-6012 (drawer) screws SCREW,SHCS,8-32,X,1/4,SS
From a Supply Drawer
94-6039 4-40 x 1/4 buttonhead screw SCREW,BHCS,4-40X1/4,SS
LCD Display and
Touch Screen Glass
94-6049 8-32 x 3/8 screw SCREW,BHCS,8-32X3/8,SS
Color Touch PC Box
94-6063 4-40 x 1/4 SHC screw SCREW,SHCS,4-40X1/4,SS
Numeric Keypad
94-6092 4-40 x 3/8 SHC screw SCREW,SHCS,4-40,X,3/8,SS
Keyboard Door Bezel
94-6095 8-32x3/8 SHC screws SCREW,SHCS,8-32,X,3/8,SS [supply cabinet]
LCD Bezel Assembly
CT PC Box Removal
94-6111 flat nut NUT,FLAT,SPRING,4-40,STEEL
Speaker
94-6133 (slide support bracket) screws
{top tray) screws [left side]
SCREW,BH,TORX,8-32,X,1/4,SS
(see
94-6181 for right side screws)
9-drawer Carrier
Ribbon Cable
94-6137 (top bayonet plate) screw SCREW,BH,TORX,6-32,X,3/16,SS
Ribbon Cable
94-6138 6-32x1/4 BH screws SCREW,BH TORX,6-32X1/4,SS [Rx cabinet]
LCD Bezel Assembly
CT PC Box Removal
Part # Part Name Agile Description Where Used
Table A-1. 1-, 2-, 3-cell cabinet service part list
