A-6 Appendix A: Part List
1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G © 2011 Omnicell, Inc.
94-6140 drawer screw SCREW,BH,TORX,4-40,X,1/8 PATCH,SS (drawer to board; right
carrier bracket to frame)
Drawer Connect
Board
Three-Drawer
Pharmacy Module
94-6142 (door) screws SCREW,BH,TORX,4-40,X,1/4,SS
Doors
94-6151 (bottom bracket) screw
[left side]
wireway screws
SCREW,FH,TORX,8-32,X,1/4,SS T15
(see
94-6181 for right bracket screw)
Restock Door
Wireway
94-6155 screws SCREW,BH,TORX,6-32,X,1/8,S (for door hinge, spacer bracket)
Three-Drawer
Pharmacy Module
94-6162 6-32 x 3/16” flathead screw
(keyboard bracket) screw
controller cable cover screw
fix inhibitor bracket screw
rail cable bracket screw
Facia bracket screw
SCREW,FH,TORX,6-32X3/16,100,DEG,C’SINK
Keyboard
LCD Bezel Assembly
9-drawer Carrier
Restock Door
Rail Frame
Three-Drawer
Pharmacy Module
94-6165 (manual override lever) screws
(top bayonet) screw
(second bayonet) screw
(bottom bayonet) screw
SCREW,BH,TORX,8-32,X,3/8,SS
9-drawer Carrier
Ribbon Cable
Bottom Bayonet
94-6172 4-40 x 1/4 flathead screw SCREW,FH,TORX,4-40X1/4,SS
LCD Display and
Touch Screen Glass
94-6173 4-40 x 3/16 SHC screw SCREW,SHCS,4-40X3/16,SS
LCD Bezel Assembly
LCD Display and
Touch Screen Glass
94-6181 (bottom bracket) screw
[right side]
(top tray) screws [right side]
SCREW,FH,TORX,8-32,X,3/8,SS NYLON,PATCH
(see
94-6151 for left side bracket screws)
(see
94-6133 for left side tray screws)
Restock Door
Ribbon Cable
94-6198 4-40 x 3/8 buttonhead screw SCREW,BH,TORX,4-40,X,3/8,SS
Keyboard Door Bezel
94-6203 8-32 x 7/8 SCREW,BH,TORX,8-32,X,7/8,SS
Color Touch PC Box
OS3DRXU Three drawer pharmacy module THREE DRAWER PHARMACY MODULE
Three-Drawer
Pharmacy Module
OSOMDT OmniDispenser OPTION KIT, OMNIDISPENSERTALL
OmniDispenser
Part # Part Name Agile Description Where Used
Table A-1. 1-, 2-, 3-cell cabinet service part list
