Doors 5-1
Introduction
Doors
Introduction
Omnicell 1-,2-, and 3-cell cabinets and half-cell units have doors that are similar, but can be
different sizes. The standard sizes for a door on a 1-, 2-, or 3-cell cabinet are: (A) full height, 2/3
height (next page), (B) 1/3 height and (C) CT PC Door.
Figure 5-1. (A) Full height door, (B) 1/3 door, and (C) CT PC door
A
B
C
