14-14 E-Box Service Guide
Remove/Replace the Power Supply
1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G © 2011 Omnicell, Inc.
Figure 14-19.
Figure 1-19.
Power supply power cable
5. Remove the power cable connected to the power supply.
Figure 14-20. Disconnect the power cable from the power supply
6. Remove the power supply from the E-Box.
Caution:
Pulling the power supply too far from the E-Box could damage the power supply
