2 Quick Start
2-4
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
V420-F with DB15 to USB/RS-232, Triggered
To Host
To Trigger
To Power Supply
To Host
(RS-232)
Integrated
Corner-Exit
Cable
Accessory
USB Cable
to Host
V420-F with IB-131 and IC-332
To
power
supply
IC-332
To external
trigger
To
Host
