2. Importing Variables with a Network Publish Attribute Created in the Sysmac Studio to the Network
Configurator
(1) Creating Tags and Tag Sets with the Network Configurator's De-
vice Parameter Editing Function
l
Creating a Tag Set
1 Double-click the icon of the device for which to create a tag set to display the Edit Device
Parameters Dialog Box. Or, right-click the icon to display the pop-up menu, and select
Parameter –
Edit.
2 Click the Tag Sets Tab at the top of the Edit Device Parameters Dialog Box.
There are two kinds of tag sets: input (consume) and output (produce).
9 Tag Data Link Functions
9-20
NX-series EtherNet/IP Unit User's Manual (W627)
