Event name Link Detected Event code 96440000 hex
Meaning Establishment of an Ethernet link was detected.
Source X Bus Ethernet Function Module Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number)
and
communications
port 1/
communications
port 2
are given
in combination
Detection tim-
ing
When a link is
established
Error attributes Level Information Recovery --- Log category System
Effects User program Continues. Operation Not affected.
Indicators Ethernet NET RUN Ethernet NET ERR Ethernet LINK/ACT
--- --- Lights.
Device variable Variable Data type Name
None --- ---
Cause and cor-
rection
Assumed cause Correction Prevention
Establishment of an Ethernet link
was detected.
--- ---
Attached infor-
mation
None
Precautions/
Remarks
None
Event name IP Address Fixed Event code 96470000 hex
Meaning The correct IP address has been determined and Ethernet communications can start.
Source X Bus Ethernet Function Module Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number) and
communications
port 1/
communications
port 2 are given
in combination
Detection tim-
ing
At power ON or
Controller reset
Error attributes Level Information Recovery --- Log category System
Effects User program Continues. Operation Not affected.
Indicators Ethernet NET RUN Ethernet NET ERR Ethernet LINK/ACT
Lights. --- ---
Device variable Variable Data type Name
None --- ---
Cause and cor-
rection
Assumed cause Correction Prevention
The correct IP address has been
determined and Ethernet commu-
nications can start.
--- ---
Attached infor-
mation
Attached information 1: IP address (example: C0A8FA01 hex = address 192.168.250.1)
Precautions/
Remarks
None
14 Troubleshooting
14-27
NX-series EtherNet/IP Unit User's Manual (W627)
14-4 Checking with the Sysmac Studio, an HMI, and Instructions That Read Error
Status
14
14-4-4 Error Details

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
