Event name Tag Data Link Connection Failed Event code 84070000 hex
Meaning Establishing a tag data link connection failed.
Source X Bus EtherNet/IP Function Mod-
ule
Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number)
and
CIP1/CIP2
are
given in combi-
nation
Detection tim-
ing
When establish-
ing a tag data
link connection
Error attributes Level Minor fault Recovery Automatic re-
covery
Log category System
Effects User program Continues. Operation The data link does not operate for a connection that
failed to establish a connection. Data links on other
connection operate.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
Flashes at 1-s intervals. Flashes at 1-s intervals. ---
Device variable Variable Data type Name
EIP_Comm1Status.TDLinkOpnErr BOOL CIP Communications1 Tag Data
Link Connection Failed
EIP_Comm2Status.TDLinkOpnErr BOOL CIP Communications2 Tag Data
Link Connection Failed
Cause and cor-
rection
Assumed cause Correction Prevention
The tag data link connection infor-
mation is not the same for the origi-
nator and target.
Modify connection information of
the tag data link and download the
device parameter or connection
settings from Network Configurator
or Sysmac Studio.
Before starting the tag data link,
match the connection information
for the tag data link in the originator
and target.
Insufficient connections Please reduce class-3 messages. Please reduce the number of data
link and class-3 messages used.
CIP message communications at
the target node are stopped.
Make the device start normal CIP
message communications.
Start CIP message communica-
tions successfully and then perform
tag data links.
Setting to use tag data link com-
munications was made to the
NX-
series EtherNet/IP Unit that is in-
cluded in the CIP Safety connec-
tion settings.
Do not configure the
NX-series
EtherNet/IP Unit, which is included
in the CIP Safety connection set-
tings, to use tag data link commu-
nications.
Do not configure the NX-series
EtherNet/IP Unit, which is included
in the CIP Safety connection set-
tings, to use tag data link commu-
nications.
The NX-series EtherNet/IP Unit
with tag data link communications
was added to the CIP Safety con-
nection settings.
Do not add the NX-series Ether-
Net/IP Unit, for which tag data link
communications are set to use, to
the CIP Safety connection settings.
Do not add the NX-series Ether-
Net/IP Unit, for which tag data link
communications are set to use, to
the CIP Safety connection settings.
Attached infor-
mation
Attached information 1: IP address of the target node (example: C0A8FA01 hex for IP address of
192.168.250.1)
Attached information 2: Connection instance No. 0 to 255
Attached information 3: Connection status (example: 010000117 hex for General Status 01 and Additional Sta-
tus 01
17)
Precautions/
Remarks
• You can know the detailed cause by checking the connection status.
Refer to
14-6-2 Connection Status Codes and Troubleshooting on page 14-55.
• If errors occur for multiple connections in one node, the event log is registered only for one connection
where an error is occurring.
14 Troubleshooting
14-35
NX-series EtherNet/IP Unit User's Manual (W627)
14-4 Checking with the Sysmac Studio, an HMI, and Instructions That Read Error
Status
14
14-4-4 Error Details
