Event name Unit Configuration Error, Combined Use of CIP Safety
and Tag Data Link
Event code 342C0000 hex
Meaning T
ag data link communications and CIP Safety communications cannot be used together in one NX-series
EtherNet/IP Unit.
Source X Bus EtherNet/IP Function Mod-
ule
Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number) and
CIP1/CIP2
are
given in combi-
nation
Detection tim-
ing
Continuously
Error attributes Level Observation Recovery --- Log category System
Effects User program Continues. Operation Not affected.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
Device variable Variable Data type Name
None --- ---
Cause and cor-
rection
Assumed cause Correction Prevention
Setting to use tag data link com-
munications was made to the
NX-
series EtherNet/IP Unit that is in-
cluded in the CIP Safety connec-
tion settings.
Do not configure the
NX-series
EtherNet/IP Unit, which is included
in the CIP Safety connection set-
tings, to use tag data link commu-
nications.
Do not configure the NX-series
EtherNet/IP Unit, which is included
in the CIP Safety connection set-
tings, to use tag data link commu-
nications.
The NX-series EtherNet/IP Unit
with tag data link communications
was added to the CIP Safety con-
nection settings.
Do not add the NX-series Ether-
Net/IP Unit, for which tag data link
communications are set to use, to
the CIP Safety connection settings.
Do not add the NX-series Ether-
Net/IP Unit, for which tag data link
communications are set to use, to
the CIP Safety connection settings.
Attached infor-
mation
None
Precautions/
Remarks
None
14 Troubleshooting
14-41
NX-series EtherNet/IP Unit User's Manual (W627)
14-4 Checking with the Sysmac Studio, an HMI, and Instructions That Read Error
Status
14
14-4-4 Error Details
