Omron NX Series User Manual

Event name Access Detected Outside Range of Variable Event code 54E00000 hex
Meaning An access attempt to write a value out of range was detected for a tag variable that is used in a tag data link.
Source X Bus EtherNet/IP Function Mod-
ule
Source details CIP1 or CIP2 Detection tim-
ing
When writing a
value to a varia-
ble
Error attributes Level Observation Recovery --- Log category System
Effects User program Continues. Operation Not affected.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
Device variable Variable Data type Name
None --- ---
Cause and cor-
rection
Assumed cause Correction Prevention
An out-of-range value was written
by an EtherNet/IP tag data link to a
variable with range specification.
A value that does not specify an
enumerator was written by an
EtherNet/IP tag data link to an enu-
meration variable.
Correct the value that is written to
the variable with range specifica-
tion so that the value is in the
range.
Correct the value that is written to
the enumeration variable so that
the value specifies an enumerator
.
W
rite values that are in range for
variables with specified ranges.
Write values that specify enumera-
tors to enumeration variables.
Attached infor-
mation
None
Precautions/
Remarks
• Write operations for out-of-range values or values that do not specify enumerators do not end normally.
• W
rite operations for in-range values or values that specify enumerators end normally.
Event name Tag Data Link Download Started Event code 94010000 hex
Meaning Changing the tag data link settings started.
Source X Bus EtherNet/IP Function Mod-
ule
Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number)
and
CIP1/CIP2
are
given in combi-
nation
Detection tim-
ing
At user opera-
tion
Error attributes Level Information Recovery --- Log category Access
Effects User program Continues. Operation Not affected.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
Flashes at 1-s intervals. --- ---
Device variable Variable Data type Name
None --- ---
Cause and cor-
rection
Assumed cause Correction Prevention
Changing the tag data link settings
started.
--- ---
Attached infor-
mation
Attached information 1: Controller status (01 hex: PROGRAM mode, 02 hex: RUN mode)
Precautions/
Remarks
None
14 Troubleshooting
14-42
NX-series EtherNet/IP Unit User's Manual (W627)
