Event name Tag Data Link Started Event code 94040000 hex
Meaning Tag data links were started by the Network Configurator, Sysmac Studio, special instructions or manipulation of
a system-defined variable. Or
, the data link table was downloaded from Network Configurator or Sysmac Stu-
dio.
Source X Bus EtherNet/IP Function Mod-
ule
Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number) and
CIP1/CIP2
are
given in combi-
nation
Detection tim-
ing
At user opera-
tion
Error attributes Level Information Recovery --- Log category Access
Effects User program Continues. Operation Not affected.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
Flashes at 1-s intervals. --- ---
Device variable Variable Data type Name
None --- ---
Cause and cor-
rection
Assumed cause Correction Prevention
Tag data links were started by the
Network Configurator
, Sysmac Stu-
dio, special instructions or manipu-
lation of a system-defined variable.
--- ---
Attached infor-
mation
Attached information 1: Controller status (01 hex: PROGRAM mode, 02 hex: RUN mode)
Attached information 2: Operation method (01 hex: Operation by Network Configurator or Sysmac Studio, 02
hex: Manipulation by a device variable, 03 hex: Manipulation by special instructions)
Attached information 3:
• When attached information 2 is 03 hex: IP address of the target node
• Other than the above: 0
Precautions/
Remarks
None
14 Troubleshooting
14-44
NX-series EtherNet/IP Unit User's Manual (W627)
