Event name Tag Data Link All Run Event code 94070000 hex
Meaning Tag data link connections to all target nodes have been normally established.
Source X Bus EtherNet/IP Function Mod-
ule
Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number)
and
CIP1/CIP2
are
given in combi-
nation
Detection tim-
ing
When establish-
ing a tag data
link connection
Error attributes Level Information Recovery --- Log category System
Effects User program Continues. Operation Not affected.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
Lights. --- ---
Device variable Variable Data type Name
EIP_Comm1Status.TDLinkAllRun-
Sta
BOOL CIP Communications1 All Tag Data
Link Communications Status
EIP_Comm2Status.TDLinkAllRun-
Sta
BOOL CIP Communications2 All Tag Data
Link Communications Status
Cause and cor-
rection
Assumed cause Correction Prevention
Tag data link connections to all tar-
get nodes have been normally es-
tablished.
--- ---
Attached infor-
mation
None
Precautions/
Remarks
None
Event name Restarting Ethernet Port Event code 96450000 hex
Meaning The EtherNet/IP port was restarted.
Source X Bus EtherNet/IP Function Mod-
ule
Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number) and
CIP1/CIP2
are
given in combi-
nation
Detection tim-
ing
At user opera-
tion
Error attributes Level Information Recovery --- Log category Access
Effects User program Continues. Operation Not affected.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
--- --- ---
Device variable Variable Data type Name
None --- ---
Cause and cor-
rection
Assumed cause Correction Prevention
The EtherNet/IP port was restart-
ed.
--- ---
Attached infor-
mation
None
Precautions/
Remarks
None
14 Troubleshooting
14-45
NX-series EtherNet/IP Unit User's Manual (W627)
14-4 Checking with the Sysmac Studio, an HMI, and Instructions That Read Error
Status
14
14-4-4 Error Details
