Omron NX Series User Manual

Connection status
Source of error
Handling
General
Status
(hex)
Additional
Status
(hex)
Configuration
1
Configuration
2
Configuration
3
01 0116 Error code returned from target:
The Major/Minor Revisions did not
match when opening connection.
Check the ma-
jor and minor
revisions set
for the target
device and
connection. If
necessary
, ob-
tain the most
recent EDS file
and set it
again.
Depends on
the target's
specifications.
(Contact the
target device's
manufacturer.)
Check that the
target device's
EDS file is cor-
rect.
Check the orig-
inator's con-
nection set-
tings.
01 01
17 Error code returned from target:
The tag set specified in the connection's
target variables does not exist.
Check whether
the originator
and target tag
sets and tags
are set correct-
ly.
Depends on
the target's
specifications.
(Contact the
target device's
manufacturer.)
Check the orig-
inator's con-
nection set-
tings. Check
whether the
target tag sets
and tags are
set correctly.
01 01
1A Error code generated by originator:
Connection could not be established be-
cause the buffer was full due to high traf-
fic.
Unexpected
network traffic
may have been
received.
If there are pla-
ces where
broadcast
storms occur
,
such as loop
connections in
the network
connection for-
mat, then cor-
rect them.
Unexpected
network traffic
may have been
received.
If there are pla-
ces where
broadcast
storms occur,
such as loop
connections in
the network
connection for-
mat, then cor-
rect them.
Depends on
the target's
specifications.
(Contact the
target device's
manufacturer.)
01 011B Error code returned from target:
The RPI was set to a value that is below
the specifications.
This error does
not occur.
Depends on
the target's
specifications.
(Contact the
target device's
manufacturer.)
Set the origina-
tor's RPI set-
ting to 1 ms or
greater.
01 0203
Error code generated by originator:
The connection timed out.
Tag data link communications from the target timed
out. Check the power supply and cable wiring of
the devices in the communications path, including
the target and switches. If performance has drop-
ped due to heavy traffic, change the performance
settings. For example, increase the timeout time or
RPI setting.
Also, check whether the CIP message communica-
tions of the target are stopped and whether the CIP
communications are permitted by Packet Filter
function of the originator or the device on the route.
14 Troubleshooting
14-58
NX-series EtherNet/IP Unit User's Manual (W627)
