Omron NX Series User Manual

Connection status
Source of error
Handling
General
Status
(hex)
Additional
Status
(hex)
Configuration
1
Configuration
2
Configuration
3
01 0113 Error code generated by originator or re-
turned from target:
Attempted to open more connections
than allowed by the specifications.
Connections of tag data link communica-
tions and CIP Safety communications
are used together
.
Check the con-
nection set-
tings (number
of connections)
at the origina-
tor and target.
Check whether
a
Unit
Configuration
Error,
Combined Use
of CIP Safety
and Tag Data
Link
(342C0000
hex) observa-
tion level event
occurred in the
NX-series
EtherNet/IP
Unit which is
on the path of
tag data link
communica-
tions.
Check the con-
nection set-
tings (number
of connections)
at the origina-
tor and target.
Check the con-
nection specifi-
cations for de-
vices from oth-
er manufactur-
ers.
Check whether
a Unit
Configuration
Error,
Combined Use
of CIP Safety
and Tag Data
Link
(342C0000
hex) observa-
tion level event
occurred in the
NX-series
EtherNet/IP
Unit which is
on the path of
tag data link
communica-
tions.
Check the con-
nection settings
(number of
connections) at
the originator
and target.
Check the con-
nection specifi-
cations for de-
vices from oth-
er manufactur-
ers.
Check whether
a Unit
Configuration
Error,
Combined Use
of CIP Safety
and Tag Data
Link
(342C0000
hex) observa-
tion level event
occurred in the
NX-series
EtherNet/IP
Unit which is
on the path of
tag data link
communica-
tions.
01 0114 Error code returned from target:
The Vendor ID and Product Code did not
match when opening connection.
This error does
not occur.
Depends on
the target's
specifications.
(Contact the
target device's
manufacturer.)
Check that the
target device's
EDS file is cor-
rect.
Check the orig-
inator's con-
nection set-
tings.
01 01
15 Error code returned from target:
The Product Type did not match when
opening connection.
This error does
not occur.
Depends on
the target's
specifications.
(Contact the
target device's
manufacturer.)
Check that the
target device's
EDS file is cor-
rect.
Check the orig-
inator's con-
nection set-
tings.
14 Troubleshooting
14-57
NX-series EtherNet/IP Unit User's Manual (W627)
14-6 Checking with the Network Configurator
14
14-6-2 Connection Status Codes and Troubleshooting
