Variable name Meaning Function Data type
Range of
values
Reference
EIP_Comm2Sta-
tus.T
argetPLCMo-
deSta[255]
CIP Communica-
tions2 Target PLC
Operating Mode
Shows the operating status of the target
node Controllers that are connected for
CIP communications 2, with the Ether-
Net/IP port as the originator.
The array elements are valid only when
the corresponding Normal T
arget Node
Information is TRUE. If the corresponding
Normal Target Node Information is
FALSE, it indicates the previous operat-
ing status.
Array[x] is TRUE:
This is the operating state of the target
Controller with a node address of x.
Array[x] is FALSE:
Other than the above.
ARRAY
[0..255] OF
BOOL
TRUE or
FALSE
page 6-27
EIP_Comm1Sta-
tus.TargetPL-
CErr[255]
CIP Communica-
tions1 Target PLC Er-
ror Information
Shows the error status (logical OR of fa-
tal and non-fatal errors) of the target
node Controllers that are connected for
CIP communications 1, with the Ether-
Net/IP ports as the originator. The array
elements are valid only when the corre-
sponding Normal T
arget Node Informa-
tion is TRUE. The immediately preceding
value is retained if this variable is FALSE.
Array[x] is TRUE:
A fatal or non-fatal error occurred in the
target Controller with a target node ID of
x.
Array[x] is FALSE:
Other than the above.
ARRAY
[0..255] OF
BOOL
TRUE or
FALSE
page 6-27
EIP_Comm2Sta-
tus.TargetPL-
CErr[255]
CIP Communica-
tions2 Target PLC Er-
ror Information
Shows the error status (logical OR of fa-
tal and non-fatal errors) of the target
node Controllers that are connected for
CIP communications 2, with the Ether-
Net/IP ports as the originator. The array
elements are valid only when the corre-
sponding Normal T
arget Node Informa-
tion is TRUE. The immediately preceding
value is retained if this variable is FALSE.
Array[x] is TRUE:
A fatal or non-fatal error occurred in the
target Controller with a target node ID of
x.
Array[x] is FALSE:
Other than the above.
ARRAY
[0..255] OF
BOOL
TRUE or
FALSE
page 6-27
