Omron NX Series User Manual

Variable name ETN_Port1Status.PortErr
Meaning Communications Port1 Error Global/local Global
Function This is the error status variable for the communications port 1.
It represents the collective status of the following error flags.
• ETN_Port1Status.MacAdrErr (Port1 MAC Address Error)
• ETN_Port1Status.LanHwErr (Port1 Communications Controller Error)
• ETN_Port1Status.EtnCfgErr (Port1 Basic Ethernet Setting Error)
• ETN_Port1Status.IPAdrCfgErr (Port1 IP Address Setting Error)
• ETN_Port1Status.IP
AdrDupErr (Port1 IP Address Duplication Error)
• ETN_Port1Status.BootpErr (Port1 BOOTP Server Error)
Note If a Link OFF Detected occurs, it is recorded in the event log and then the corresponding bit
turns ON. Refer to Meanings of Error Status Bits on page 6-10 for the meanings of the error
status bits.
Data type WORD Range of values 16#0000 to 16#00F0
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name ETN_Port2Status.PortErr
Meaning Communications Port2 Error Global/local Global
Function This is the error status variable for the communications port 2.
It represents the collective status of the following error flags.
• ETN_Port2Status.MacAdrErr (Port2 MAC Address Error)
• ETN_Port2Status.LanHwErr (Port2 Communications Controller Error)
• ETN_Port2Status.EtnCfgErr (Port2 Basic Ethernet Setting Error)
• ETN_Port2Status.IPAdrCfgErr (Port2 IP Address Setting Error)
• ETN_Port2Status.IP
AdrDupErr (Port2 IP Address Duplication Error)
• ETN_Port2Status.BootpErr (Port2 BOOTP Server Error)
Note If a Link OFF Detected occurs, it is recorded in the event log and then the corresponding bit
turns ON. Refer to Meanings of Error Status Bits on page 6-10 for the meanings of the error
status bits.
Data type WORD Range of values 16#0000 to 16#00F0
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name ETN_Port1Status.MacAdrErr
Meaning Port1 MAC Address Error Global/local Global
Function Indicates that an error occurred when the MAC address was read on the communications port 1 at startup.
TRUE: Error
F
ALSE: Normal
Data type BOOL Range of values TRUE or F
ALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-17
NX-series EtherNet/IP Unit User's Manual (W627)
6-3 Specifications for Individual Device Variables
6
