Variable name Meaning Function Data type
Range of
values
Reference
EIP_Comm1Sta-
tus.T
agAdrErr
CIP Communica-
tions1 Tag Name
Resolution Error
Indicates that the tag resolution for CIP
communications 1 failed (i.e., the ad-
dress could not be identified from the tag
name).
TRUE: Tag resolution failed (i.e., the ad-
dress could not be identified from the tag
name). The following causes are possi-
ble.
• The size of the network variable is dif-
ferent from the tag settings.
• The I/O direction that is set in the tag
data link settings does not agree with
the I/O direction of the variable in the
NX-series EtherNet/IP Unit
.
• There is no network variable in the
NX-series EtherNet/IP Unit that corre-
sponds to the tag setting.
FALSE: Other than the above.
BOOL TRUE or
F
ALSE
page 6-23
EIP_Comm2Sta-
tus.TagAdrErr
CIP Communica-
tions2 Tag Name
Resolution Error
Indicates that the tag resolution for CIP
communications 2 failed (i.e., the ad-
dress could not be identified from the tag
name).
TRUE: Tag resolution failed (i.e., the ad-
dress could not be identified from the tag
name). The following causes are possi-
ble.
• The size of the network variable is dif-
ferent from the tag settings.
• The I/O direction that is set in the tag
data link settings does not agree with
the I/O direction of the variable in the
NX-series EtherNet/IP Unit
.
• There is no network variable in the
NX-series EtherNet/IP Unit that corre-
sponds to the tag setting.
FALSE: Other than the above.
BOOL TRUE or
F
ALSE
page 6-24
*1. Refer to Meanings of Error Status Bits on page 6-10 for the meanings of the error status bits.
l
Meanings of Error Status Bits
The meanings of the individual bits in the following error status are the same.
• ETN_ErrSta
(Communications Port Error)
• EIP_ErrSta (CIP Communications Error)
• ETN_Port1Status.PortErr
(Communications Port1 Error)
• ETN_Port2Status.PortErr (Communications Port2 Error)
• EIP_Comm1Status.CipErr (CIP Communications1 Error)
• EIP_Comm2Status.CipErr (CIP Communications2 Error)
The meanings of the individual bits are shown in the following table.
1 31 5 14 1 2
-
1
1
---
-
-
1 0
-
9
-
8
-
7
-
6
5 4
-
3
-
1
-
2
-
0
Bit:
WORD
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-10
NX-series EtherNet/IP Unit User's Manual (W627)
