Variable name EIP_Comm2Status.TDLinkOpnErr
Meaning CIP Communications2 Tag Data Link Connec-
tion Failed
Global/local Global
Function Indicates that establishing a tag data link connection for CIP communications 2 failed.
TRUE: Establishing a tag data link connection failed due to one of the following causes.
• The information registered for a target node in the tag data link parameters is dif
ferent from the actual node
information.
• There was no response from the remote node.
F
ALSE: Other than the above.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm1Status.TDLinkErr
Meaning CIP Communications1 Tag Data Link Communi-
cations Error
Global/local Global
Function Indicates that a timeout occurred in a tag data link connection for CIP communications 1.
TRUE: A timeout occurred.
FALSE: Other than the above.
Data type BOOL Range of values TRUE or F
ALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm2Status.TDLinkErr
Meaning CIP Communications2 Tag Data Link Communi-
cations Error
Global/local Global
Function Indicates that a timeout occurred in a tag data link connection for CIP communications 2.
TRUE: A timeout occurred.
F
ALSE: Other than the above.
Data type BOOL Range of values TRUE or F
ALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm1Status.TagAdrErr
Meaning CIP Communications1 Tag Name Resolution
Error
Global/local Global
Function Indicates that the tag resolution for CIP communications 1 failed (i.e., the address could not be identified from the
tag name).
TRUE: T
ag resolution failed (i.e., the address could not be identified from the tag name). The following causes are
possible.
• The size of the network variable is dif
ferent from the tag settings.
• The I/O direction that is set in the tag data link settings does not agree with the I/O direction of the variable in
the NX-series EtherNet/IP Unit.
• There is no network variable in the NX-series EtherNet/IP Unit that corresponds to the tag setting.
FALSE: Other than the above.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-23
NX-series EtherNet/IP Unit User's Manual (W627)
6-3 Specifications for Individual Device Variables
