Bit Description
15 to 6 Reserved.
5 This bit indicates whether a minor fault level Controller error has occurred.
TRUE: A minor fault level Controller error has occurred.
F
ALSE: A minor fault level Controller error has not occurred.
4 This bit indicates whether an observation level Controller error has occurred.
TRUE: An observation level Controller error has occurred.
FALSE: An observation level Controller error has not occurred.
3 to 0 Reserved.
l
Functional Classification: NX-series EtherNet/IP Unit Status
Variable name Meaning Function Data type
Range of
values
Reference
ETN_Port1Status.Et-
nOnlineSta
Port1 Online Indicates that the EtherNet/IP port's com-
munications can be used via the commu-
nications port 1 (that is, the link is ON, IP
address is defined, and there are no er-
rors.)
TRUE: The EtherNet/IP port’s communi-
cations can be used.
F
ALSE: The EtherNet/IP port’s communi-
cations is disabled due to an error in ini-
tial processing, restart processing, or link
OFF status.
BOOL TRUE or
FALSE
page 6-24
ETN_Port2Status.Et-
nOnlineSta
Port2 Online Indicates that the EtherNet/IP port's com-
munications can be used via the commu-
nications port 2 (that is, the link is ON, IP
address is defined, and there are no er-
rors.)
TRUE: The EtherNet/IP port’s communi-
cations can be used.
F
ALSE: The EtherNet/IP port’s communi-
cations is disabled due to an error in ini-
tial processing, restart processing, or link
OFF status.
BOOL TRUE or
FALSE
page 6-24
EIP_Comm1Sta-
tus.TDLinkRunSta
CIP Communica-
tions1 Tag Data Link
Communications Sta-
tus
Indicates that at least one connection is
in normal operation in CIP communica-
tions 1.
TRUE: Normal operation
FALSE: Other than the above.
BOOL
TRUE or
FALSE
page 6-24
EIP_Comm2Sta-
tus.TDLinkRunSta
CIP Communica-
tions2 Tag Data Link
Communications Sta-
tus
Indicates that at least one connection is
in normal operation in CIP communica-
tions 2.
TRUE: Normal operation
FALSE: Other than the above.
BOOL
TRUE or
FALSE
page 6-25
EIP_Comm1Sta-
tus.TDLinkAllRunSta
CIP Communica-
tions1 All Tag Data
Link Communications
Status
Indicates that all tag data links are com-
municating in CIP communications 1.
TRUE: Tag data links are communicating
in all connections as the originator
.
FALSE: An error occurred in at least one
connection.
BOOL TRUE or
FALSE
page 6-25
EIP_Comm2Sta-
tus.TDLinkAllRunSta
CIP Communica-
tions2 All Tag Data
Link Communications
Status
Indicates that all tag data links are com-
municating in CIP communications 2.
TRUE: Tag data links are communicating
in all connections as the originator
.
FALSE: An error occurred in at least one
connection.
BOOL TRUE or
FALSE
page 6-25
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-11
NX-series EtherNet/IP Unit User's Manual (W627)
