Force Server Blade to be SAS2 Capable
Note - The Force SAS2 3 Gbps property in Oracle ILOM is disabled by default.
This procedure provides both web and command-line interface (CLI) instructions for the chassis
monitoring module (CMM).
Force Server Blade to be SAS2 Capable
To force NEMs to run SAS2 links at a slower rate (3Gbps) in an Oracle blade
chassis system:
■ From the Web interface:
a.
Click System Management > Policy.
b.
In the Chassis Monitoring Module Policies table, select Force server
blade to be SAS2 capable at 3Gbps for the appropriate blade server
module, and then select Enable or Disable in the Actions list box.
c.
Click Save to apply your changes.
■ From the CLI, type:
set /CH/BLn/policy FORCE_SAS2_3GBPS= enabled|disabled
See Also
Set CMM Blade Slot Grant Limit Property, Oracle ILOM Configuration and Maintenance
Guide for firmware version 3.1 or 3.2.
Setting the Low-Line AC Override Mode Policy on Sun
Server X4-4 (Oracle ILOM)
On a Sun Server X4-4 with four processors, the default Oracle ILOM configuration is to
prevent the system from powering on if the power supplies are not connected to high-line (220-
114 Oracle X4 Series Servers Administration Guide • April 2016
