Navigate the BIOS Setup Utility Menus
■
Options that can be modified are highlighted when you press the up and down arrow keys.
■
If a field can be modified, as you select the option, instructions for modifying the option
appear in the right column of the screen.
■
If a field is a link to a sub-screen, a description of the sub-menu content appears in the right
column.
4.
Modify the setup field by pressing the + or - keys (plus or minus keys) or by
pressing Enter and selecting the option you want from the dialog box menus.
5.
To return from a sub-menu to the previous menu screen, press the Esc key.
Pressing Escape from a top-level menu is equivalent to selecting the Discard Changes and Exit
option from the Save and Exit menu.
6.
Modify parameters as needed.
7.
To save or discard your changes and exit the BIOS Setup Utility, press F10.
To save your changes and exit the BIOS Setup Utility, you can select the Save & Exit menu and
then select Save Changes and Reset.
Note - After you modify any BIOS settings and select Save Changes and Reset from the Save
& Exit menu, the subsequent reboot might take longer than a typical reboot where no settings
were modified. The additional delay is required to ensure that changes to the BIOS settings are
synchronized with Oracle ILOM.
Note - If the BIOS Setup Utility setup data is invalid, the BIOS settings return to their factory
default values.
See Also
■
For BIOS screen details, see your server service manual.
BIOS Key Mappings
When you view the BIOS output from a terminal using the Oracle ILOM remote console
feature, some terminals do not support function keys. BIOS supports the mapping of function
keys to Control key sequences when serial redirection is enabled. The following table provides
a description of the function key to Control key mappings.
194 Oracle X4 Series Servers Administration Guide • April 2016
