387
FEB 2008Ver. 1.1
DP-C405/C305/C265
CN553-5 *B
FTR and LSU
Shutter Motor
Sub Motor Phase B
CN553-6 A
FTR and LSU
Shutter Motor
FTR/STR/Fuser/Sub Motor
Phase A
CN553-7 *B Fuser Motor Sub Motor Phase B
CN553-8 +24VM Fuser Motor +24V DC Power Supply
CN553-9 B Fuser Motor Motor Phase B
CN553-10 *A Fuser Motor Sub Motor Phase A
CN553-11 +24VM Fuser Motor +24V DC Power Supply
CN553-12 A Fuser Motor
FTR/STR/Fuser/Sub Motor
Phase A
MOTDRV
PCB Pin No.
Signal Name Destination Signal Waveform Function
+24V
0V
+24V
0V
+24V
0V
+24V
0V
+24V
0V
+24V
0V
+24V
0V
+24V
0V
