849
DP-C405/C305/C265
FEB 2008Ver. 1.1
12.1.5.2.2. Punch Unit (Option)
1. Sensors
Fig. 5-010
Table 5-004
Name Notation Description
Photo-interrupters PI1P Puncher home position detection
PI2P Horizontal registration home position detection
PI3P Punch motor clock detection
PI3P
PI1P
PI2P
