4. E7-57, Punch Sensor (Horizontal Registration) Fault
Table 5-029
5. E7-58, Punch Sensor (Waste Full) Fault
Table 5-030
6. E7-29, Horizontal Registration Motor Fault
Table 5-031
Horizontal Registration Sensor (Photo Sensor PCB / LED PCB)
1) Check the horizontal registration sensor. Is the sensor normal?
NO :Replace the sensor.
Wiring
2) Is the wiring between the punch controller PCB and the horizontal registration
sensor normal?
NO :Correct the wring.
Punch Controller PCB, Finisher Controller PCB
3) Try replacing the punch controller PCB. Is the problem correct?
YES:End.
NO :Replace the Finisher Controller PCB.
Waste Full Sensor (Waste Full Photo Sensor PCB / Waste Full LED PCB)
1) Check the waste full sensor. Is the sensor normal?
NO :Replace the sensor.
Wiring
2) Is the wiring between the punch controller PCB and the waste full sensor
normal?
NO :Correct the wring.
Punch Controller PCB, Finisher Controller PCB
3) Try replacing the punch controller PCB. Is the problem corrected?
YES:End.
NO :Replace the Finisher Controller PCB.
Horizontal Registration Home Position Sensor (PI2P)
1) Check the horizontal registration home position sensor. Is the sensor normal?
NO :Replace the sensor.
Wiring
2) Is the wiring between the Finisher Controller PCB and the horizontal registration
home position sensor normal?
NO :Correct the wring.
Horizontal Registration Mechanism, Horizontal Registration Motor (M2P)
3) Is there a fault in the horizontal registration mechanism?
YES:Correct the horizontal registration mechanism.
NO :Replace the horizontal registration motor.
Punch Controller PCB, Finisher Controller PCB
4) Try replacing the punch controller PCB. Is the problem corrected?
YES:End.
NO :Replace the Finisher Controller PCB.
