Parameter Reference D-137
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Lower Input
This is connected to a Digital Input as part of the selected Macro. When TRUE causes Output to ramp down.
Raise Lower Output
1905
Monitor::Application::Raise Lower
0.0
-500.0 to 500.0
NEVER
The ramp output monitor. Output is preserved during the power-down of the Drive.
Functional Description
The table below describes how Output is controlled by Raise Input, Lower Input and Reset Input.
Reset
Raise Input
Raise Output
Action
TRUE
Any
Any
Output tracks Reset Value
FALSE
TRUE
FALSE
Output ramps up to Maximum Value at Ramp Time
FALSE
FALSE
TRUE
Output ramps down to Minimum Value at Ramp Time
FALSE
FALSE
FALSE
Output not changed. *
FALSE
TRUE
TRUE
Output not changed. *
* If Output is greater than Maximum Value the Output will ramp down to Maximum Value at Ramp Time. If Output is less
than Minimum Value the Output will ramp up to Minimum Value at Ramp Time.
IMPORTANT: If Maximum Value is less than or equal to Minimum Value, then Output is set to Maximum Value.
