Parker AC30 User Manual

Parameter Reference D-59
AC30 series Variable Speed Drive
Energy Meter
Monitor::Energy Meter
Parameters::Motor Control::Energy Meter
This feature measures the electrical energy used by the motor.
Parameter Name
No.
Path
Default
Range
Units
Writable
Power kW
0380
Monitor::Energy Meter
Parameters::Motor Control::Energy
Meter
x.xx
0.00 to 1000000.00
kW
NEVER
This diagnostic shows the power being delivered to the load in kilowatts.
Power HP
0381
Same as PNO 380
x.xx
0.00 to 1000000.00
HP
NEVER
This diagnostic shows the power being delivered to the load in horsepower.
Reactive Power
0382
Same as PNO 380
x.xx
0.00 to 1000000.00
kVAr
NEVER
This diagnostic shows the reactive power being delivered to the load in kilo volt-amperes reactive.
Energy kWh
0383
Same as PNO 380
x.xx
0.00 to 10000000.00
kWh
NEVER
This diagnostic shows the total energy consumed by the load in kilowatt hours.
Power Factor Est
0385
Same as PNO 380
x.xx
0.00 to 1.00
NEVER
This diagnostic shows the power factor estimate (between 0 and 1).
Power Factor Angle Est
0386
Parameters::Motor Control::Energy
Meter
x.xx
0.00 to 90.00
deg
NEVER
This diagnostic shows the power factor angle estimate.

Parker AC30 Specifications

General

Protection Rating	IP20
Series	AC30
Type	Variable Frequency Drive
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Communication Protocols	CANopen
Power Range	0.75 to 250 kW (1 to 350 hp)
Switching Frequency	2kHz to 16kHz
Safety	Safe Torque Off (STO)
Output Current	Model Dependent
Power Rating	0.75 to 250 kW (1 to 350 hp)
Efficiency	>97%
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overheating
Dimensions	Model Dependent
Weight	Model Dependent
Operating Temperature	-10°C to +40°C
Output Voltage	0 to Input Voltage
