Parker AC30 User Manual

Technical Specifications F-26
AC30 series Variable Speed Drive
ENCODER TRANSMIT OUTPUTS – AC30D ONLY
ENCT-A (X33/01), ENCT-/A (X33/02), ENCT-B (X33/03), ENCT-/B (X33/04), ENCT-Z (X33/05), ENCT-/Z (X33/06)
Signalling Type
Differential: A to /A, B to /B and Z to /Z
Output Voltage Levels
Selectable:
Off-load nominal output (differential) voltages: 5V, 12V, 15V or 20V
Rated-load nominal output (differential) voltages: 4.0V, 10.8V, 13.9V or 18.9V (respectively)
Rated Output Current
33mA
(100mA total for all three outputs combined)
Maximum Count
Frequency
250kHz pulse rate
Resolution of Output
Period
7ns (0.18% @ 250kHz)
Operating Modes
Selectable:
Repeat of Encoder Input 1
Repeat of Encoder Input 2
Synthetic encoder output
Digital outputs (general purpose)
Propagation Delay in
Repeat Mode
< 1μs
Protection
Short-circuit protected.

Parker AC30 Specifications

General

Protection Rating	IP20
Series	AC30
Type	Variable Frequency Drive
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Communication Protocols	CANopen
Power Range	0.75 to 250 kW (1 to 350 hp)
Switching Frequency	2kHz to 16kHz
Safety	Safe Torque Off (STO)
Output Current	Model Dependent
Power Rating	0.75 to 250 kW (1 to 350 hp)
Efficiency	>97%
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overheating
Dimensions	Model Dependent
Weight	Model Dependent
Operating Temperature	-10°C to +40°C
Output Voltage	0 to Input Voltage
