F-1 Technical Specifications
AC30 series Variable Speed Drive
Appendix F: Technical Specifications
Understanding the Product Code
MODEL NUMBER
The unit is fully identified using a four block alphanumeric code which records how the drive was calibrated, and its various settings when dispatched
from the factory. This can also be referred to as the Product Code.
AC30 Family Drive Example of Product Coding Scheme:
Block 2 Block 3
3 1 V - 4 D 0004 - B F - 2 S 0000
Family AC30 Configured Drive 3
AC70 Stack Only 7
IP Rating IP20 AC Fed 1
IP20 DC Fed 4
Industry Industry, AC30V Versatile (AC30 Only) V
Industry, AC30P Advanced Inverter (AC30 Only) P
Industry, AC30D Advanced Inverter with dual encoder system option (AC30 Only) D
Industry, AC70 None (AC70 Only) 0
Supply voltage:
AC 380V / 480V - DC 510V / 650V 4
Frame
kW hp kW hp Size
Rating Data: 1.1 1.5 0.75 1.0 D D 0004
1.5 2.0 1.1 1.5 D D 0005
2.2 3.0 1.5 2.0 D D 0006
3.0 (n/a) 2.2 3.0 D D 0008
4.0 5.0 3.0 (n/a) D D 0010
5.5 7.5 4.0 5.0 D D 0012
7.5 10 5.5 7.5 E E 0016
11 15 7.5 10 E E 0023
15 20 11 15 F F 0032
18 25 15 20 F F 0038
22 30 18 25 G G 0045
30 40 22 30 G G 0060
37 50 30 40 G G 0073
45 60 37 50 H H 0087
55 75 45 60 H H 0105
75 100 55 75 H H 0145
90 125 75 100 J J 0180
110 150 90 125 J J 0205
132 200 110 150 J J 0260
160 250 132 200 K K 0315
200 300 160 250 K K 0380
250 350 200 300 K K 0440
Brake Switch Not Fitted (Frames H & J Only) N
Brake switch fitted B
EMC filter None N
Category C3 (AC supplied only) E
Category C2 (AC supplied only) F
GKP Not Fitted 0
Blank Fitted 1
GKP Fitted 2
Conformal Coating Standard 3C3 S
Enhanced E
Special Option None 0000
