Associated Equipment 5-11
AC30 series Variable Speed Inverter
Control Terminal Cover Removal
First remove the GKP by pulling from the top down and
remove.
Undo the screw and slide the control terminal cover down,
then remove
Control Terminal Cover
INSTALLATION DETAILS
HAZARDOUS VOLTAGES may be present on GPIO module motor thermistor user relays, please refer to the option technical manual or main
product manual for safety information
