Parker AC30 User Manual

Parameter Reference D-55
AC30 series Variable Speed Drive
Encoder Slot 1
Parameters::System Board::Encoder Slot 1
This feature allows you to setup and monitor the operation of the encoder attached to slot 1 of the system board.
Parameter Name
No.
Path
Default
Range
Units
Writable
Encoder Supply
1663
Setup::Inputs and Outputs::SB Encoder
Slot1
Parameters::System Board::Encoder
Slot 1
0
0:5 V
1:12 V
2:15 V
3:20 V
STOPPED
Configures the encoder supply for both Encoder 1 and Encoder 2
Encoder Lines
1664
Same as PNO 1663
2048
1 to 100000
STOPPED
The number of lines per encoder revolution
Encoder Invert
1665
Same as PNO 1663
FALSE
STOPPED
Reverses the encoder direction if TRUE.
Encoder Type
1666
Same as PNO 1663
0
0:QUADRATURE
1:CLOCK/DIRECTION
Normally the encoder will be quadrature. Exceptionally, eg if a proximity sensor or other pulse train is used, it needs to be clock /
direction.
High Input Threshold
1667
Same as PNO 1663
FALSE
STOPPED
Changes the threshold level for the encoder pulses between 1.8 V and 6.5 V typical. For encoders powered from 5 V the low theshold
should be used. For other supply voltages the high threshold will provide greater noise immunity.
Encoder Speed
1668
Parameters::System Board::Encoder
Slot 1
RPM
NEVER
The speed measured by the encoder, in revolutions per minute.

Parker AC30 Specifications

General

Protection Rating	IP20
Series	AC30
Type	Variable Frequency Drive
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Communication Protocols	CANopen
Power Range	0.75 to 250 kW (1 to 350 hp)
Switching Frequency	2kHz to 16kHz
Safety	Safe Torque Off (STO)
Output Current	Model Dependent
Power Rating	0.75 to 250 kW (1 to 350 hp)
Efficiency	>97%
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overheating
Dimensions	Model Dependent
Weight	Model Dependent
Operating Temperature	-10°C to +40°C
Output Voltage	0 to Input Voltage
