Parker AC30 User Manual

D-54 Parameter Reference
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Encoder Speed
1516
Monitor::Inputs and Outputs
Parameters::Option IO::Encoder
x.
Min to Max
RPM
NEVER
The speed measured by the encoder, in revolutions per minute.
Encoder Count Reset
1517
Same as PNO 1511
FALSE
ALWAYS
If set to TRUE resets the encoder count.
Encoder Count
1518
Same as PNO 1516
-214783648 to 214783647
NEVER
This parameter shows the encoder count, which is a 32 bit counter that will increment and decrement with the encoder pulses, up to
2^31 or down to -2^31.

Parker AC30 Specifications

General

Protection Rating	IP20
Series	AC30
Type	Variable Frequency Drive
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Communication Protocols	CANopen
Power Range	0.75 to 250 kW (1 to 350 hp)
Switching Frequency	2kHz to 16kHz
Safety	Safe Torque Off (STO)
Output Current	Model Dependent
Power Rating	0.75 to 250 kW (1 to 350 hp)
Efficiency	>97%
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overheating
Dimensions	Model Dependent
Weight	Model Dependent
Operating Temperature	-10°C to +40°C
Output Voltage	0 to Input Voltage
