Parker AC30 User Manual

Safety 1-1
AC30 series Variable Speed Inverter
Chapter 1: Safety
Safety Information
Please read these important Safety notes before installing and operating this equipment
CAUTION
CAUTION notes in the manual warn of danger to equipment.
WARNING
NOTES IN THE MANUAL WARN OF DANGER TO PERSONEL
Requirements
Intended Users
This manual is to be made available to all persons who are required to install, configure or service equipment described herein, or any other
associated operation.
The information given is intended to highlight safety issues, and to enable the user to obtain maximum benefit from the equipment.
Complete the following table for future reference detailing how the unit is to be installed and used.
INSTALLATION DETAILS
Model Number
(see product label)
Where installed
(for your own
information)
Unit used as a:
(refer to
Certification)
Component Relevant Apparatus
Unit fitted:
Cubicle mounted
Through Panel Mounted
Application Area
The equipment described is intended for industrial motor speed control utilising AC induction motors or AC permanent magnet synchronous
machines.

Parker AC30 Specifications

General

Protection Rating	IP20
Series	AC30
Type	Variable Frequency Drive
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Communication Protocols	CANopen
Power Range	0.75 to 250 kW (1 to 350 hp)
Switching Frequency	2kHz to 16kHz
Safety	Safe Torque Off (STO)
Output Current	Model Dependent
Power Rating	0.75 to 250 kW (1 to 350 hp)
Efficiency	>97%
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overheating
Dimensions	Model Dependent
Weight	Model Dependent
Operating Temperature	-10°C to +40°C
Output Voltage	0 to Input Voltage
