Philips LPC2101 - C Control Set Register (I2 CONSET: I2 C0, I2 C0 CONSET - 0 Xe001 C000 and I2 C1, I2 C1 CONSET - 0 Xe005 C000)

© Koninklijke Philips Electronics N.V. 2006. All rights reserved.
User manual Rev. 01 — 12 January 2006 128
Philips Semiconductors
UM10161
Volume 1
Chapter 11: I
2
C interfaces
[1] Reset value reflects the data stored in used bits only. It does not include reserved bits content.
11.7.1 I
2
C Control Set register (I2CONSET: I2C0, I2C0CONSET - 0xE001 C000
and I2C1, I2C1CONSET - 0xE005 C000)
The I2CONSET registers control setting of bits in the I2CON register that controls
operation of the I
2
C interface. Writing a one to a bit of this register causes the
corresponding bit in the I
2
C control register to be set. Writing a zero has no effect.
I2EN I
2
C Interface Enable. When I2EN is 1, the I
2
C interface is enabled. I2EN can be
cleared by writing 1 to the I2ENC bit in the I2CONCLR register. When I2EN is 0, the I
2
C
interface is disabled.
When I2EN is “0”, the SDA and SCL input signals are ignored, the I
2
C block is in the “not
addressed” slave state, and the STO bit is forced to “0”.
I2EN should not be used to temporarily release the I
2
C-bus since, when I2EN is reset, the
I
2
C-bus status is lost. The AA flag should be used instead.
STA is the START flag. Setting this bit causes the I
2
C interface to enter master mode and
transmit a START condition or transmit a repeated START condition if it is already in
master mode.
I2SCLH SCH Duty Cycle Register High Half Word. Determines
the high time of the I
2
C clock.
R/W 0x04 0xE001 C010
I2C0SCLH
0xE005 C010
I2C1SCLH
I2SCLL SCL Duty Cycle Register Low Half Word. Determines
the low time of the I
2
C clock. I2nSCLL and I2nSCLH
together determine the clock frequency generated by an
I
2
C master and certain times used in slave mode.
R/W 0x04 0xE001 C014
I2C0SCLL
0xE005 C014
I2C1SCLL
I2CONCLR I
2
C Control Clear Register. When a one is written to a
bit of this register, the corresponding bit in the I
2
C control
register is cleared. Writing a zero has no effect on the
corresponding bit in the I
2
C control register.
WO NA 0xE001 C018
I2C0CONCLR
0xE005 C018
I2C1CONCLR
Table 120: I
2
C register map
Name Description Access Reset
value
[1]
I
2
C0 Address
and Name
I
2
C1 Address
and Name
Table 121: I
2
C Control Set register (I2CONSET: I2C0, I2C0CONSET - address 0xE001 C000
and I2C1, I2C1CONSET - address 0xE005 C000) bit description
Bit Symbol Description Reset
value
1:0 - Reserved. User software should not write ones to reserved bits. The
value read from a reserved bit is not defined.
NA
2 AA Assert acknowledge flag. See the text below.
3SI I
2
C interrupt flag. 0
4 STO STOP flag. See the text below. 0
5 STA START flag. See the text below. 0
6I2EN I
2
C interface enable. See the text below. 0
7 - Reserved. User software should not write ones to reserved bits. The
value read from a reserved bit is not defined.
NA
