© Koninklijke Philips Electronics N.V. 2006. All rights reserved.
User manual Rev. 01 — 12 January 2006 242
Philips Semiconductors
UM10161
Volume 1 Chapter 19: Flash memory
19.9 IAP commands
For in application programming the IAP routine should be called with a word pointer in
register r0 pointing to memory (RAM) containing command code and parameters. Result
of the IAP command is returned in the result table pointed to by register r1. The user can
reuse the command table for result by passing the same pointer in registers r0 and r1. The
parameter table should be big enough to hold all the results in case if number of results
are more than number of parameters. Parameter passing is illustrated in the Figure 63
.
The number of parameters and results vary according to the IAP command. The
maximum number of parameters is 5, passed to the "Copy RAM to FLASH" command.
The maximum number of results is 2, returned by the "Blankcheck sector(s)" command.
The command handler sends the status code INVALID_COMMAND when an undefined
command is received. The IAP routine resides at 0x7FFF FFF0 location and it is thumb
code.
The IAP function could be called in the following way using C.
Define the IAP location entry point. Since the 0th bit of the IAP location is set there will be
a change to Thumb instruction set when the program counter branches to this address.
#define IAP_LOCATION 0x7ffffff1
Define data structure or pointers to pass IAP command table and result table to the IAP
function:
unsigned long command[5];
6 COUNT_ERROR Byte count is not multiple of 4 or is not a permitted
value.
7 INVALID_SECTOR Sector number is invalid or end sector number is
greater than start sector number.
8 SECTOR_NOT_BLANK Sector is not blank.
9 SECTOR_NOT_PREPARED_FOR_
WRITE_OPERATION
Command to prepare sector for write operation was
not executed.
10 COMPARE_ERROR Source and destination data not equal.
11 BUSY Flash programming hardware interface is busy.
12 PARAM_ERROR Insufficient number of parameters or invalid
parameter.
13 ADDR_ERROR Address is not on word boundary.
14 ADDR_NOT_MAPPED Address is not mapped in the memory map. Count
value is taken in to consideration where applicable.
15 CMD_LOCKED Command is locked.
16 INVALID_CODE Unlock code is invalid.
17 INVALID_BAUD_RATE Invalid baud rate setting.
18 INVALID_STOP_BIT Invalid stop bit setting.
19 CODE_READ_PROTECTION_
ENABLED
Code read protection enabled.
Table 225: ISP Return codes Summary
Return
Code
Mnemonic Description
