The values for I2SCLL and I2SCLH should not necessarily be the same. Software can set
different duty cycles on SCL by setting these two registers. For example, the I
2
C-bus
specification defines the SCL low time and high time at different values for a 400 kHz I
2
C
rate. The value of the register must ensure that the data rate is in the I
2
C data rate range
of 0 through 400 kHz. Each register value must be greater than or equal to 4. Tabl e 1 28
gives some examples of I
2
C-bus rates based on PCLK frequency and I2SCLL and
I2SCLH values.
11.8 Details of I
2
C operating modes
The four operating modes are:
• Master Transmitter
• Master Receiver
• Slave Receiver
• Slave Transmitter
Data transfers in each mode of operation are shown in Figure 32
, Figure 33, Figure 34,
Figure 35
, and Figure 36. Tabl e 1 29 lists abbreviations used in these figures when
describing the I
2
C operating modes.
Table 128: Example I
2
C clock rates
I2SCLL +
I2SCLH
I
2
C Bit Frequency (kHz) at PCLK (MHz)
1 5 10 16 20 40 60
8125
10 100
25 40 200 400
50 20 100 200 320 400
100 10 50 100 160 200 400
160 6.25 31.25 62.5 100 125 250 375
200 5 25 50 80 100 200 300
400 2.5 12.5 25 40 50 100 150
800 1.256.2512.520 25 50 75
I
2
C
bitfrequency
PCLK
I2CSCLH I2CSCLL+
---------------------------------------------------------
=
Table 129: Abbreviations used to describe an I
2
C operation
Abbreviation Explanation
S Start Condition
SLA 7-bit slave address
R Read bit (HIGH level at SDA)
W Write bit (LOW level at SDA)
