© Koninklijke Philips Electronics N.V. 2006. All rights reserved.
User manual Rev. 01 — 12 January 2006 75
Philips Semiconductors
UM10161
Volume 1 Chapter 8: GPIO
Aside from the 32-bit long and word only accessible FIOMASK register, every fast GPIO
port can also be controlled via several byte and half-word accessible registers listed in
Tabl e 7 0
. Next to providing the same functions as the FIOMASK register, these additional
registers allow easier and faster access to the physical port pins.
8.4.3 GPIO port 0 Pin value register (IOPIN, Port 0: IO0PIN - 0xE002 8000;
FIOPIN, Port 0: FIO0PIN - 0x3FFF C014)
This register provides the value of port pins that are configured to perform only digital
functions. The register will give the logic value of the pin regardless of whether the pin is
configured for input or output, or as GPIO or an alternate digital function. As an example,
a particular port pin may have GPIO input or GPIO output, UART receive, and PWM
output as selectable functions. Any configuration of that pin will allow its current logic state
to be read from the IOPIN register.
If a pin has an analog function as one of its options, the pin state cannot be read if the
analog configuration is selected. Selecting the pin as an A/D input disconnects the digital
features of the pin. In that case, the pin value read in the IOPIN register is not valid.
Writing to the IOPIN register stores the value in the port output register, bypassing the
need to use both the IOSET and IOCLR registers to obtain the entire written value. This
feature should be used carefully in an application since it affects the entire port.
The legacy register is the IO0PIN, while the enhanced GPIOs are supported via the
FIO0PIN register. Access to a port pins via the FIOPIN register is conditioned by the
corresponding FIOMASK register (see Section 8.4.2 “
Fast GPIO port 0 Mask register
(FIOMASK, Port 0: FIO0MASK - 0x3FFF C010)”).
Only pins masked with zeros in the Mask register (see Section 8.4.2 “
Fast GPIO port 0
Mask register (FIOMASK, Port 0: FIO0MASK - 0x3FFF C010)”) will be correlated to the
current content of the Fast GPIO port pin value register.
Table 70: Fast GPIO port 0 Mask byte and half-word accessible register description
Register
name
Register
length (bits)
& access
Address Description Reset
value
FIO0MASK0 8 (byte) 0x3FFF C010 Fast GPIO Port 0 Mask register 0. Bit 0 in FIO0MASK0 register
corresponds to P0.0 ... bit 7 to P0.7.
0x00
FIO0MASK1 8 (byte) 0x3FFF C011 Fast GPIO Port 0 Mask register 1. Bit 0 in FIO0MASK1 register
corresponds to P0.8 ... bit 7 to P0.15.
0x00
FIO0MASK2 8 (byte) 0x3FFF C012 Fast GPIO Port 0 Mask register 2. Bit 0 in FIO0MASK2 register
corresponds to P0.16 ... bit 7 to P0.23.
0x00
FIO0MASK3 8 (byte) 0x3FFF C013 Fast GPIO Port 0 Mask register 3. Bit 0 in FIO0MASK3 register
corresponds to P0.24 ... bit 7 to P0.31.
0x00
FIO0MASKL 16
(half-word)
0x3FFF C001 Fast GPIO Port 0 Mask Lower half-word register. Bit 0 in
FIO0MASKL register corresponds to P0.0 ... bit 15 to P0.15.
0x0000
FIO0MASKU 16
(half-word)
0x3FFF C012 Fast GPIO Port 0 Mask Upper half-word register. Bit 0 in
FIO0MASKU register corresponds to P0.16 ... bit 15 to P0.31.
0x0000
